RFID Proximity Mid Range Smart Card Reader Communication With
Wiegand 26
Rfid proximity mid range reader main used for parking, elevator,
logistics industry,etc.125Khz EM Reader is most used for door
access system. It is working at 125Khz is suitable for most widely
used RFID Cards some times called as Proximity card also.Middle
range reader, JUTAI EM Proximity Mid Range Reader, access control
reader distance 65-100CM. 10 years reader manufacture and
experience in rfid reader.
JUTAI as the proximity long range reader wholesale, it provides
long range RFID proximity readers and RFID Proximity Mid Range
Smart Card Reader which can be installed with barrier gate within
130cm distance. Using the credentialed RFID proximity reader, the
barrier gate system will automatically open the gate when a vehicle
is approaching towards the gate. JUTAI aims to manufacture the best
long-range proximity reader and EM card for a non-stop vehicle
parking system, access control system in all kinds of areas, create
a totally hands-free ideal vehicle access control
125Khz EM GP66 RFID Proximity Mid Range Smart Card Readeris most
used for door access system. It is working at 125Khz is suitable
for most widely used RFID Cards some times called as Proximity card
also.Middle range reader, JUTAI EM proximity mid range reader,
access control reader distance 65-100CM JUTAI factory have 10 years
experience in rfid reader. JUTAI company in the RFID reader in the
industry. We have proven technique to production GP66 EM 125khz
middle range reader.
Features
Can penetrate solar film (V-Kool40)
Auto tuning function to compensate presence of metal and
interference
Extended reading range from 65cm to 100 cm
Bright LED indicators, tuning LED bar
Firmware up gradable in the field
IP-65 waterproof housing design
High-quality power supply with noise filter included
Loop Inductive function optional
Anti-rereading function included.
Function And Advantage
GP-66 is more stronger and long reading distance than other similar
RFID readers
GP-66 reading range up to 1 meters and it have strong working mode
and anti-interference ability, long distance, stable working, high
resistance to metal pollution.
Can penetrate any brand solar film and low cost rfid solution
Comparing with other frequency RFID reader, GP-66 can penetrate any
brands solar filmin market to offer affordable 1m reading range
without winding down car window. Its reading range will not be
effected or decrease 3-5CM by the V-KOOL( vehicle solar film).
Totally hands free access control solution
GP-66 with EM card,card sticker,so you no need to stop your car and
wind down yourcar window to read card. Other similar products need
to stop car to read card orflash card. So GP-66 hands free solution
can save your time and more safe.
Strong ability to adapt the environment
GP-66 and high quality power supply with noise filter included.
That adopt low rippleprocessing technology,which can effectively
resist any external interference source andbe affordable work in
any environment.
Easy to integrate into any company access control system and easy
to upgrade the old projects
GP-66 can effectively integrate with any company with their own
access controlsystem, also with Weigand 26/ Wiegand 34 interface,
RS485/RS232 interface,that will be more convenient to update the
system or management for our users.
Connection Line Denfinition
| NO. | Color | Fuction | Description |
| 1 | Red | + 12V | 12V Power |
| 2 | Black | GND |
| 3 | Green | D0 | Wigand Signal Qutput |
| 4 | Yellow | D1 |
| 5 | Gray | TXD | Rs232 |
| 6 | Light Blue | RXD |
| 7 | Purple | Loop Signal A | Loop Signal Input |
| 8 | Blue | Loop Signal B |
| 9 | Orange | Wigand Qutput Cable | Orange and Light greentogether:wigand26Disconnect-wigand34 |
| 10 | Light Green | Wigand Output Cable |
| 11 | White | RS485-A | NC |
| 12 | Brown | RS485-B |
